Cloud 46-80T

Key features

1. Eight input (6 x line, 2 x mic) mixing amplifier for four zones
2. 4 x 80 W power output, 70/100 V-line version also available (46-80T)
3. CXL-80T 70/100 V-line transformers may be retrofitted per-channel to 46-80
4. Slave mode: power amplifier stages may be paralleled in various configurations and fed from a single programme source
5. Peak limiter to protect power amplifier stages and loudspeakers
6. Utility/Loop output with independent mic/music mix and user-definable music source
7. Balanced, line level aux outputs (pre-power stage) from Zones 1 and 2
8. Four balanced and two unbalanced stereo line inputs with individual gain trim controls
9. Two balanced mic inputs; 15 V phantom power selectable on either or both
10. Zone 1 Facility Port for connection of optional remote input plates: LM-2 mic/line input + music controls, BT-1 Bluetooth input, L-1 line input, M-1 mic input
11. Music Mute control input (N/O or N/C) for emergency alarm system
12. Compatible with standard Cloud remote control panels: RL Series (music level) and RSL Series (music level and source selection), per-zone
13. RS-232 port for serial control of per-Zone MIC 1 muting, music level and source plus global unit standby, Music Mute and MIC 2 muting
14. User–selectable Automatic Power Down for maximum energy efficiency
15. Convection-cooled (no fan): silent in operation
