Ecler VIDA-48Q
Dante™/AES67 Digital Amplifier with DSP and Player
Our Part No. 19074
Manufacturers Part No. VIDA-48Q
Description
4800W digital amplifier, with 4 amplified outputs that can be independently configured in high (100/70V) or low (8/4/2ohm) impedance. The VersaPower technology, developed by Ecler, allows an asymmetrical power distribution. Max output power @ 2Ω/4Ω/8Ω or @70/100V - Single channel is 4800W. Audio player - with microSD slot for local audio files – as well as signal generator, plus 2 auxiliary line outputs and 4 Dante digital outputs. Internal matrix and signal processing. Remote control user application for iOS/Android/Web. Control and scheduled events for automation. Ultra low power consumption mode. Dimensions 482,6x88(2RU)x410 mm / 19"x3.46"x16.14". Weight 9,3 kg. / 20.5 lb.
List price *
£3,127.65
Key features
- 4 amplified outputs VersaPower asymmetrical 4800W power management
- 4 Dante™ outputs and 4 Dante™/AES67 inputs
- 2 auxiliary outputs
- 4 analogue inputs
- MicroSD/SDHC audio player
- Internal matrix and signal processing
- Web application for device configuration
- Smart power management VersaPower
- Control and scheduled events for automation
- Customized User Panels
- Remote control user application for iOS/Android/Web
- Ultra low power consumption mode "Sleep Mode"
Tech Specs
- Number of output channels: 4
- Max output power @ 100V: 1200W
- Frequency response: 15Hz-25kHz (-3dB, 1W any load)
- SNR (Signal-to-Noise Ratio): 95 dBA (40dB Gain, from 20Hz - 20kHz)
- Amplification technology: Class D
- Power supply: Universal, regulated SMPS with PFC
